| Bore X Stroke (mm) |
68 x 45 mm |
| Compression ratio |
9.0 : 1 |
| Displacement (cm3) |
163 |
| Fuel Tank Capacity (L) |
3.1 Liter |
| Ignition System |
Transistorised |
| Model |
GX160 |
| Dimensions (L x W x H) |
312 x 362 x 346 mm |
| Fuel cons. at cont. rated power |
1.4 L/h – 3600 rpm |
| Engine |
4-stroke single cylinder, OHV petrol engine, horizontal shaft |
| Net Power kW(ps)/rpm |
3.2 kW ( 4.3 HP ) / 3600 rpm |
| Engine Weight Dry (kg) |
15.1kg |
| Cont rated power |
2.5 kW ( 3.4 HP ) / 3000 rpm, 2.9 kW ( 3.9 HP ) / 3600 rpm |
| Max. net torque |
10.3 Nm / 1.05 kgfm / 2500 rpm |
| Engine Oil Capacity |
0.6 Liter |
