| UAS Main Features |
Flight Time |
25 Minutes |
| |
Payload |
10 Liters |
| |
Weight |
25 Kg |
| |
Category |
Small |
| |
Power |
4 kW |
| Frame Parameters |
Max Diagonal Wheelbase (Folded) |
655 × 515 × 630 mm |
| |
Arms Folded, Propellers Unfolded |
169 × 51795 × 630 mm (Possible Typo) |
| |
Arms Unfolded, Propellers Folded |
1030 × 1120 × 630 mm |
| |
Type |
Multirotor |
| |
Configuration |
Quadcopter |
| Remote Control |
Weight |
490g (controller), 26g (receiver), 15.6g (camera) |
| |
Channel |
12 |
| |
Working Voltage |
3.7V |
| |
Working Current |
170mA |
| |
Battery Capacity |
4000mAh |
| |
Endurance |
25 hours |
| |
Frequency |
2.400–2.4833 GHz |
| |
Communication |
FHSS |
| |
Operational Distance |
500 meters (Video/Data) |
| |
Signal Output |
SBUS, PWM, I2C |
| Flight Characteristics |
Max Attainable Altitude |
50 feet |
| |
Hovering Accuracy |
±1 m (horizontal) |
| |
Max Yaw Speed |
150°/s |
| |
Max Vertical Speed |
6 m/s |
| |
Working Temperature Range |
-10°C to 60°C |
| Propulsion System |
Stator Size |
100 × 10 mm |
| |
KV Rating |
100 rpm/V |
| |
Pull Force |
13.5 kg/rotor |
| |
Rotor Type |
BLDC |
| |
No. of Rotors |
4 |
| |
Propeller Spec. |
30 × 9 inch |
| |
Propeller Weight |
90g |
| ESC |
Max Working Current |
FOC 100A |
| |
Max Working Voltage |
44.4V (12S LiPo) |
| Spray System |
Medicine Tank Volume |
10 Liters |
| |
Medicine Box Weight |
0.9 kg |
| |
Nozzle Type |
Single Pressure Nozzle |
| |
Pump Flow Rate |
5 L/min |
| |
Operating Voltage |
44.4V |
| |
Spraying Width |
4–6 m |
| Mini Camera |
Resolution |
720P @ 30 fps |
| |
Dimensions |
30.2 × 29.8 × 26.8 mm |
| |
Weight |
15.6g |
| |
Voltage |
5V |
| |
Current |
180mA |
| |
Temperature Range |
-10°C to +40°C |
| Power Battery |
Voltage |
44.4V (12S) |
| |
Capacity |
16000mAh |
| |
Weight |
3.6 kg |
| |
Size |
170 × 110 × 236 mm |
| |
Charging Plug |
XT90 Socket |
| |
Magnifying Power |
25C |
| Dual Charger |
Input Voltage |
100–240V |
| |
Output Power |
1080W (540W × 2) |
| |
Discharging Power |
50W × 2 |
| |
Charging Range |
1.0–20.0A × 2 |
| |
Balance Current |
1.2A Max |
| |
Battery Type |
LiPo / LiHV |
| |
Battery Cell Count |
6S × 2 |
| |
Charging Modes |
Fast Charge / Balance / Storage |
| |
Charger Size |
272 × 202 × 118.6 mm |
