Description
Performance | Endurance | 23 mins+ |
Maximum Speed | 7 m/s | |
Area Coverage in Single Charge | 3 Acre | |
Airframe | Dimensions | 543 x 355 x 46.5 mm |
UAV Weight (No Payload) | 22.0 Kg | |
UAV Weight (With Payload) | 37.2 Kg | |
Foldable Arms | Yes | |
Weight | 1840 g | |
Propulsion System | Max Thrust | 19.2 kg/rotor |
Max Power | 3804 W/rotor | |
Propeller Specification | 34.7 x 11 | |
Battery | Type | Li-Po 12S (DC 44.4V) |
Camera and Lights | Night Operation | Yes |
Strobe Light | Yes | |
Field of View (FOV) | 120° | |
ESC | Max Current | 120A |
Max Voltage | DC 44–50.4V | |
Tank | Tank Capacity | 15L Max |
Tank Weight | 1128 g | |
Communication | Operating Range | 1 km (Restricted through Geo-Fencing) |
Operating Altitude (AGL) | 50 m | |
GSM Connectivity | 4G LTE | |
Cloud Dashboard | NEXTUAV | |
Remote Log Data Transfer | Yes (Over the Cloud) | |
Payload | Fertilizer Tank | Yes |
Tank Capacity | 15L | |
Removable Tank | Yes | |
Spray System | Nozzles | Single Nozzle ×4 |
Pump Flow Rate | 5 L/min Max | |
Spray Span | 4.5–6 m |
